Dronetag Mini
Full Price
Pay in One Payment
We take every precaution to ensure your order arrives safely, but in rare cases, damage may occur during shipping. The return process depends on the shipping method, and following the correct steps is essential to qualify for a replacement. From documenting damage to handling claims, our guide covers everything you need to know to protect your purchase.
For details on returns, freight shipments, and battery policies, be sure to review our full policy.
We stand by the quality of our products and work closely with manufacturers to ensure you receive the best possible support. While some items may come with a manufacturer warranty, terms vary by product. If you receive a defective item, our team will guide you through the warranty process and coordinate with the manufacturer for repairs or replacements. Please note that Raptor does not issue refunds for damaged or defective items.
For full details on warranty coverage and the return process please see our warranty policy.
Drone Protection Plans
Hey there! Quick question, are you still just relying on basic drone insurance? That’s a bit like bringing an umbrella to a hurricane! Protect your drone (and your sanity) with Raptor’s Drone Protection Plan. Seriously, it’s the backup you didn’t know you needed.
FAA
Our consulting services help you get the FAA spraying drone approvals you’ll need… and we do it fast!
Product Features
n/a
Capacity
n/a
Coverage
n/a
Max Flow Rate
Cellular
LTE-M and Narrowband IoT (NB-IoT)
Cellular bands
3, 8, 20 for the EU and 2, 4, 12 for the US
Short-range radio
Bluetooth 2.4GHz
Sensors
GNSS, barometer, accelerometer
Positioning
GPS L1, GLONASS L1, Galileo E1, SBAS
SIM card
Chip SIM soldered on the mainboard
Built-in Antennas
Internal LTE, Bluetooth and GNSS
Optional Antennas
External LTE and Bluetooth via MMCX plugs
External ports
3.3V extension connector and 5V Micro USB
Battery
LiPo 3.7V 500 mAh
Battery life
8-14 hours (depending on the configuration)
Charging
5V Micro USB
Charging time
2 hours from a discharged state
Average current consumption
50mA
Maximum current consumption
1A
Enclosure
plastic
Fastening mechanism
3M Dual-lock SJ4570
IP rating
IP43
Operating temperature
-20 °C to +60 °C (-4 °F to 140 °F)
Dimensions
54x35x15 mm (2.1x1.3x0.6 in)
Weight
32 grams (1.1 oz)
n/a
Capacity
n/a
Coverage
n/a
Max Flow Rate
Cellular
LTE-M and Narrowband IoT (NB-IoT)
Cellular bands
3, 8, 20 for the EU and 2, 4, 12 for the US
Short-range radio
Bluetooth 2.4GHz
Sensors
GNSS, barometer, accelerometer
Positioning
GPS L1, GLONASS L1, Galileo E1, SBAS
SIM card
Chip SIM soldered on the mainboard
Built-in Antennas
Internal LTE, Bluetooth and GNSS
Optional Antennas
External LTE and Bluetooth via MMCX plugs
External ports
3.3V extension connector and 5V Micro USB
Battery
LiPo 3.7V 500 mAh
Battery life
8-14 hours (depending on the configuration)
Charging
5V Micro USB
Charging time
2 hours from a discharged state
Average current consumption
50mA
Maximum current consumption
1A
Enclosure
plastic
Fastening mechanism
3M Dual-lock SJ4570
IP rating
IP43
Operating temperature
-20 °C to +60 °C (-4 °F to 140 °F)
Dimensions
54x35x15 mm (2.1x1.3x0.6 in)
Weight
32 grams (1.1 oz)
Dronetag Mini
|
---|
