DJI Agras T50 (Ready to Fly Kit)



DJI Agras T50 (Ready to Fly Kit)
Description
Shipping & Return Policy
We take every precaution to ensure your order arrives safely, but in rare cases, damage may occur during shipping. The return process depends on the shipping method, and following the correct steps is essential to qualify for a replacement. From documenting damage to handling claims, our guide covers everything you need to know to protect your purchase.
For details on returns, freight shipments, and battery policies, be sure to review our full policy.
Warranty
We stand by the quality of our products and work closely with manufacturers to ensure you receive the best possible support. While some items may come with a manufacturer warranty, terms vary by product. If you receive a defective item, our team will guide you through the warranty process and coordinate with the manufacturer for repairs or replacements. Please note that Raptor does not issue refunds for damaged or defective items.
For full details on warranty coverage and the return process please see our warranty policy.

Drone Protection Plans
Hey there! Quick question, are you still just relying on basic drone insurance? That’s a bit like bringing an umbrella to a hurricane! Protect your drone (and your sanity) with Raptor’s Drone Protection Plan. Seriously, it’s the backup you didn’t know you needed.

FAA
Our consulting services help you get the FAA spraying drone approvals you’ll need… and we do it fast!

Product Features
Specifications
Aircraft
-
Weight
- 39.9 kg (excl. battery)
52 kg (incl. battery)
-
Max Takeoff Weight[1]
- Max takeoff weight for spraying: 92 kg (at sea level)
Max takeoff weight for spreading: 103 kg (at sea level)
-
Max Diagonal Wheelbase
- 2200 mm
-
Dimensions
- 2800×3085×820 mm (arms and propellers unfolded)
1590×1900×820 mm (arms unfolded and propellers folded)
1115×750×900 mm (arms and propellers folded)
-
Hovering Accuracy Range (with strong GNSS signal)
- RTK enabled:
Horizontal: ±10 cm, Vertical: ±10 cm
RTK disabled:
Horizontal: ±60 cm, Vertical: ±30 cm (radar module enabled: ±10 cm)
-
RTK/GNSSOperating Frequency
- RTK:
GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS L1/L2
GNSS:
GPS L1, GLONASS F1, BeiDou B1I, Galileo E1, QZSS L1
-
Max Configurable Flight Radius
- 2000 m
-
Max Wind Resistance
- 6 m/s
Propulsion System - Motors
-
Stator Size
- 100×33 mm
-
KV
- 48 rpm/V
-
Power
- 4000 W/rotor
Propulsion System - Propellers
-
Material
- Nylon carbon fiber filament
-
Dimension
- 54 in (1371.6 mm)
-
Propeller Rotation Diameter
- 1375 mm
-
Quantity
- 8
Dual Atomizing Spraying System - Spray Tank
-
Material
- Plastic (HDPE)
-
Volume
- 40 L
-
Operating Payload [1]
- 40 kg[1]
-
Quantity
- 1
Dual Atomizing Spraying System - Sprinklers
-
Model
- LX8060SZ
-
Quantity
- 2
-
Nozzle Distance
- 1570 mm(Rear Nozzles)
-
Droplet Size
- 50-500 μm
-
Effective Spray Width [2]
- 4-11 m (at a height of 3 m above the crops)
Dual Atomizing Spraying System - Delivery Pumps
-
Type
- Impreller pump (magnetic drive)
-
Quantity
- 2
-
Single Pump Flow Rate
- 0-12 L/min
-
Max Flow Rate
- 16 L/min (2 sprinklers); 24 L/min (4 sprinklers)
T50 Spreading System
-
Compatible Material Diameter
- 0.5-5 mm dry granules
-
Spread Tank Volume
- 75 L
-
Spread Tank Internal Load [10]
- 50 kg
-
Spread Width
- 8 m
Phased Array Radar System
-
Model
- RD241608RF (forward phased array radar); RD241608RB (rear phased array radar)
-
Terrain Follow
- Max slope in mapping-free operation: 50°
Altitude detection range: 1-50 m
Stabilization working range: 1.5-30 m
-
Obstacle Avoidance [4]
- Obstacle sensing range (multidirectional): 1-50 m
FOV:
Forward phased array radar: horizontal 360°, vertical ±45°, upward ±45° (cone)
Rear phased array radar: vertical 360°, horizontal ±45°
Working conditions: flying higher than 1.5 m over the obstacle at a horizontal speed no more than 10 m/s and vertical speed no more than 3 m/s.
Safety limit distance: 2.5 m (distance between the front of propellers and the obstacle after braking)
Sensing direction: 360° multidirectional sensing
Binocular Vision System
-
Measurement range
- 0.5-29 m
-
Effective Sensing Speed
- ≤10 m/s
-
FOV
- Horizontal: 90°, Vertical: 106°
-
Operating Environment
- Adequate light and discernible surroundings
Remote Controller
-
Model
- RM700B
-
Operating Frequency [5]
- 2.4000-2.4835 GHz, 5.725-5.850 GHz
-
Max Transmission Distance
- 7 km (FCC), 5 km (SRRC), 4 km (MIC/CE); (unobstructed, free of interference, and at an altitude of 2.5 m)
-
Wi-Fi Protocol
- Wi-Fi 6
-
Wi-Fi Operating Frequency [5]
- 2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz
-
Bluetooth Protocol
- Bluetooth 5.1
-
Bluetooth Operating Frequency
- 2.4000-2.4835 GHz
-
GNSS
- GPS+Galileo+BeiDou
-
Screen
- 7.02-in LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2
-
Operating Temperature
- -20° to 50° C (-4° to 122° F)
-
Storage Temperature Range
- Less than one month: -30° to 45° C (-22° to 113° F)
One to three months: -30° to 35° C (-22° to 95° F)
Six months to one year: -30° to 30° C (-22° to 86° F)
-
Charging Temperature
- 5° to 40° C (41° to 104° F)
-
Internal Battery Runtime
- 3 hours 18 minutes
-
External Battery Runtime
- 2 hours 42 minutes
-
Charging Type
- It is recommended to use a locally certified USB-C charger at a maximum rated power of 65 W and maximum voltage of 20 V such as the DJI 65W Portable Charger.
-
Charging Time
- 2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger)
