XAG P150 (Spray All Day Kit)

(4.5) • 2 reviews

18.5 Gal (70L) Capacity

tbd Coverage

8 GPM (30LPM) Max Flow Rate

30.9 mph Max Speed

up to 33 ft (up to 10 meters) Max Swath

4D imaging Radar + Radar Terrain Following Safety

18.5 Gal (70L) Capacity

tbd Coverage

8 GPM (30LPM) Max Flow Rate

30.9 mph Max Speed

up to 33 ft (up to 10 meters) Max Swath

4D imaging Radar + Radar Terrain Following Safety

XAG P150 (Spray All Day Kit)

(4.5) • 2 reviews

Full Price

$42,999.00

Pay in One Payment

Description

Smarter Farming Starts Here. Boost your farm's productivity with the XAG P150 agricultural drone. Cover more ground faster with its 18.5 gal capacity and a whopping 40 mph flight speed!

Overview:

"Expected Spring/Summer 2025" - XAG RevoTransport
Effortlessly handles long distances and steep terrains. The P150 features the new XAG RevoTransport system, offering both sling and cargo transport modes. With fast loading and unloading capabilities, it enables efficient transport, overcoming terrain and distance limitations while reducing manual labor and transportation costs.

AG RevoSpray 4
Faster, Better and More Economical Spraying Performance
Precision, uniformity, and efficiency are key to improving crop protection for fields and orchards. The new generation XAG ReSpray system delivers a maximum flow rate of 30 liters per minute (7.93 gallons/min) with uniform atomization, ensuring effective spraying even during high-speed flight. Up to 4 centrifugal nozzles6,combined with the quadrotor's powerful airflow, allow thorough penetration into tall, dense canopies, achieving even coverage on both leaf surfaces.

XAG RevoCast4
Exceptional spreading performance,delivering real efficiency
Spreading tasks are demanding and require higher performance from agricultural drones.The P150, equipped with the new XAG RevoCast system, spreads a full bag of fertilizer in 11 seconds, leading the industry in efficiency. It is compatible with three types of augers to support various needs, including fertilizing, seeding, feeding, and powder spreading.

XAG RealTerra3
One-click mapping for fieldsand orchards with rapid image output
Equipped with the XAG RealTerra system, the P150 autonomously flies to capture high-resolution images, performs automatic image stitching, and generates real-time 3D models. It can efficiently complete high-definition mapping tasks for fields and orchards, with a single mapping area of up to 32 acres

Power System
Rapid Charging
Four Battery Sets (x8) for Continuous Operation
Time is of the essence in agricultural tasks, and charging efficiency is crucial. With the new water-mist cooling solution, charging begins immediately upon landing. Multiple charging options are available, with the fastest charging time being just 8 minutes. Additionally, economical and eco-friendly new energy charging solutions are offered, helping you take off fully charged and ready to work.

- B13970S Smart Supercharged Battery
- Battery Mist Cooling Tower
- GC4000+Mobile Supercharging Station
- CM13600 Super Charger
- CM210600 New Energy Vehicle-Mounted Charger
- CM15300D Energy Storage Charger

XAG SRC4 Remote Controller with Screen - Flexible Assistance for Efficient Operations

SuperX 5 Pro Intelligent Control System
Empowering agricultural drones with the most advanced "brain". With a simplified flight control architecture and automotive-grade chip, it boasts ten times the computational power of the previous generation. This powers advanced features such as environmental sensing, flight control, data transmission, and RTK navigation, enabling the P150 to perform autonomous flights and operate with exceptional efficiency.

XAG Agronomy Services 5.0
Fully autonomous operation with user-friendly controls, ideal for beginners

Intelligent Route Planning:
- Automatically plans the optimal flight route based on field shapes and parameters.
- Automatically returns to base when low on pesticides or battery.
- Automatically selects the best route to resume operations after interruptions.

Multi-Drone Control:
- Supports controlling two drones simultaneously for autonomous operations, increasing efficiency with parallel workflows.

Multi-Field Combined Operations:
- Supports selecting up to 10 fields in one go to generate continuous operation routes.
- Once a field is completed, the drone automatically flies to the next, saving time and effort.

Team Collaboration:
- Enables multiple users to share field data, operation records, and more, ensuring smooth collaboration.
- Automatically syncs with the XAG Farm Service Management Platform for real-time team coordination and pest management updates.

Comprehensive Mapping Options:
- Offers multiple mapping methods, including touchscreen plotting, flight-based plotting, and handheld mapper plotting.
- Supports multi-field mapping mode, making it easy to measure adjacent fields seamlessly.

Spray All Day Kit:

x1 XAG P150 2024 Agricultural Drone (INTL)
x1 XAG P150 RevoSpray 4 (INTL)
x1 XAG Smart Remote Controller SRC4 (INTL)
x8 XAG B13970S Smart Supercharge Battery (INTL)
x2 XAG CM13600 Super Charger (INTL)
x2 XAG 2024 Battery Cooling Tower (INTL)
x2 XAG 2024 Battery Cooling Tower Modification Kit (INTL)
x1 XAG XRTK6 Pro Ground Module (EN)

Shipping & Return Policy

We take every precaution to ensure your order arrives safely, but in rare cases, damage may occur during shipping. The return process depends on the shipping method, and following the correct steps is essential to qualify for a replacement. From documenting damage to handling claims, our guide covers everything you need to know to protect your purchase.

For details on returns, freight shipments, and battery policies, be sure to review our full policy.

Warranty

We stand by the quality of our products and work closely with manufacturers to ensure you receive the best possible support. While some items may come with a manufacturer warranty, terms vary by product. If you receive a defective item, our team will guide you through the warranty process and coordinate with the manufacturer for repairs or replacements. Please note that Raptor does not issue refunds for damaged or defective items.

For full details on warranty coverage and the return process please see our warranty policy.

Package: Spray All Day Package

Spray All Day Package

Quantity:

12-month limited warranty

Drone Protection Plans

Hey there! Quick question, are you still just relying on basic drone insurance? That’s a bit like bringing an umbrella to a hurricane! Protect your drone (and your sanity) with Raptor’s Drone Protection Plan. Seriously, it’s the backup you didn’t know you needed.

FAA

Our consulting services help you get the FAA spraying drone approvals you’ll need… and we do it fast!

See Products

XAG P150 (Spray All Day Kit)

$42,999.00

Accessories

Save $119.00

XAG B13970S Smart Supercharge Battery

$1,380.00

$1,499.00

Save $94.00

XAG CM13600 AC Charger

$1,250.00

$1,344.00

XAG Smart Remote Controller SRC4

$2,358.00

XAG RevoCast4

$2,618.00

XAG XRTK6 Pro Ground Module (EN)

$1,900.00

XAG DL1 Data Link

$950.00

XAG 2024 Battery Cooling Tower

$150.00

XAG Battery Cooling Tower Plug Kit (INTL)

$35.20

Product Features

Overview

18.5 Gal (70L)

Capacity

tbd

Coverage

8 GPM (30LPM)

Max Flow Rate

Specifications

Flight Platform

Basic Parameters

Dimensions

122.4×122.8×31.7 in (Propellers deployed, including XAG Revo Spray 4 P150 version)

67.9×68.2×31.7 in (Propellers folded, including XAG Revo Spray 4 P150 version)

41.5×43.5×31.7 in (Propellers and arms folded, including XAG Revo Spray 4 P150 version)

Flight Platform Weight (with battery)

116.8 lbs (With XAG Revo Spray 4 P150 version and battery)

127.9 lbs (With XAG Revo Broadcast 4 P150 version and battery)

Symmetrical Motor Axis Distance

86.8 in

Arm Tube Material

Aluminum Alloy

Protection Rating

IPX6K

Rated Take-off Weight

249.1 lbs (Rated spray take-off weight)

282.2 lbs (Rated broadcast take-off weight)

Flight Parameters

Duration of High-Precision Navigation under RTK Data Delay

Limited to RTK data delay of 600 seconds

Maximum Take-off Altitude

6562 ft (Above 2000 m affects flight efficiency)

Maximum Flight Speed

30.9 mph

Recommended Operating Temperature

32 ~ 104 °F

Hovering Accuracy (with good GNSS signal)

With RTK: Horizontal 4 in, Vertical 4 in

Without RTK: Horizontal ±23.6 in, Vertical ±11.8 in

Maximum Flight Height

98.4 ft

Power System

Motor

Model

A55

Maximum Thrust (Single Motor)

121.3 lbs

Rated Power (Single Motor)

4700 W

Electronic Speed Controller (ESC)

Model

XESC-F360

Continuous Output Current

120 A

Maximum Output Current (30s)

360 A

Foldable Propellers

Rotor Material

Carbon Fiber Composite

Rotor Diameter

60.2 in

XAG RevoSpray 4 P150 Version

Smart Medicine Tank

Rated Tank Capacity

18.5 gal

Rated Tank Load

154.3 lbs

Centrifugal Atomizing Nozzles

Quantity

2 Units

Atomized Droplet Size

60 ~ 400 μm (Depending on spray flow rate, environment, etc.)

Spray Disc Rotation Speed

1500 ~ 16000 rpm

Spray Width

16.4 ~ 32.8 ft (Depending on flight speed, height, dosage, environment, etc.)

Flexible Impeller Pump

Quantity

2 Units

Voltage

50 V

Maximum System Flow Rate

7.9 gal/min (Dual Pump)

Single Pump Flow Rate

0.13 ~ 3.96 gal/min

XAG RevoCast 4 P150 Version

Smart Material Tank

Rated Tank Capacity

30.4 gal

Rated Tank Load

154.3 lbs

Variable Spiral Feeder

Number of Feeders

1 Unit

Maximum Speed

15000 rpm

Maximum Discharge Rate

617.3 lbs/min (Measured in the lab using compound fertilizer; data affected by particle size, shape, density, and dryness)

Operating Temperature

32 ~ 104 °F

Storage Temperature

32 ~ 104 °F

Broadcasting Particle Size Range

Particle Diameter: 0.04 ~ 0.39 in

Centrifugal Broadcasting Disc

Number of Discs

1 Unit

Maximum Speed

5400 rpm

Broadcast Width

9.8 ~ 26.2 ft (Depending on flight altitude, seed weight, shape, dosage, and environment)

XAG Revo Transportation System

Suspension Transport

Maximum Transport Load

143.3 lbs

Module Dimensions

33.8×23.4×20.9 in

Hook Dimensions

φ5.45 × h6.54 in

Cargo Ground Release

Supported

Rope Length

Supports 16.4 ~ 49.2 ft (Adjustable manually)

Cargo Swing Detection

Supported

Hook Protection Rating

IP56

Charging Method

Type-C Charging

Cargo Swing Reduction

Supported

Charging Voltage/Current

5V / 2A

Cabin Transport

Maximum Transport Load

143.3 lbs

Module Dimensions

29.9×26.8×29.5 in

Cabin Volume Dimensions

28.7×23.6×16.5 in

XAG RealTerra 3

Revo Mapping System Dimensions

33.8×23.4×21.0 in

Image Format

JPEG

Image Sensor

1200 MP

Power

10 W

Lens

Focal Length 2.7 mm

Recommended Operating Temperature

50 ~ 113 °F

Shutter Type

Mechanical Shutter

Perception and Obstacle Avoidance System

4D Imaging Radar

Model

RD2488

Measurement Range

4.9 ~ 328.1 ft

Operating Voltage

24 V

Field of View (FOV)

Horizontal ±40°; Vertical +90° to -45°

Power

10 W

Safe Obstacle Avoidance Relative to Ground Height

≥4.9 ft

Operating Frequency

24 GHz

Safe Obstacle Avoidance Distance

8.2 ft (Distance between rotor tip and obstacle after braking to stable hover)

Perception Method

Beamforming, 4D Imaging

Safe Obstacle Avoidance Relative Speed

≤30.9 mph

Perception Parameters

Azimuth, Pitch, Distance, Speed

Terrain Following Radar

Model

TR24S100_24

Operating Frequency

24 GHz

Operating Voltage

5 V

Height Measurement Range

1.6 ~ 328.1 ft (Relative height from crop surface)

Power

1.3 W

Height Stabilization Range

3.3 ~ 98.4 ft (Relative height from crop surface)

Perception Method

Millimeter Wave

Maximum Slope

45° (Flight speed ≤2 m/s)

FPV First-Person View (FPV) Imaging

Video Resolution

1920 x 1080

Power Supply Voltage

24 V

Frame Rate

30 fps

Video Encoding Format

H.264 / H.265

Image Sensor

1/2.8 inch CMOS-RGB Image Sensor, 2 MP

Focal Length

Forward FPV (2.7 mm)

Downward FPV (2.7 mm)

Power System

XAG B13970S Smart Super-Charge Battery

Model

M1PPA13970B

Rated Output

48.75 V/140 A

Battery Type

Polymer Lithium-Ion Battery

Maximum Charging Current

100 A

Rated Capacity

20 Ah

Charging Environment Temperature

50 ~ 113 °F

XAG CM13600 Charger

Model

M2CM1-3600A

Input Voltage

AC, 100 - 120 Vac, 50/60 Hz, 15.0 A

AC, 220 - 240 Vac, 50/60 Hz, 16.0 A

Number of Output Ports

1 Unit

Output Voltage

56.6 Vdc

Output Power

1300 W (100 - 120 Vac, 50/60 Hz)

3400 W (220 - 240 Vac, 50/60 Hz)

Operating Environment Temperature

-4 ~ 104 °F

XAG GC4000+ Mobile Super-Charge Station

Model

GC4000+

Net Weight

69.4 lbs

Fuel Tank Capacity

3.96 gal

Total Displacement

223 cc

Output Voltage

56.6 Vdc

Rated Current

75 ±3 A

Rated Charging Power

3400 W

Maximum Output Power

5100 W

XAG CM15300D Energy Storage Charger

Model

M2CM15300DA

Number of Output Ports

1 Unit

Output Power

5000W

Input Voltage

(60~100)Vdc

Output Voltage

56.6 Vdc

Output Current

100A

Operating Environment Temperature

-4 ~ 104 °F

XAG CM210600 Onboard Charger

Model

M2CM210600A

Number of Output Ports

2个

Output Power

Output 1: 5000 W (300 ~ 500 Vdc)

Output 2: 5000 W (300 ~ 500 Vdc)

Input Voltage

300 ~ 500 Vdc, 35.0 A (MAX)

Output Voltage

Output 1: 56.6 Vdc

Output 2: 56.6 Vdc

Output Current

Output 1: 100A(Max)/5000W(300~500Vdc)

Output 2: 100A(Max)/5000W(300~500Vdc)

Operating Environment Temperature

-4 ~ 104 °F

XAG 2024 Battery Mist Cooling Box

Model

M8BC5A

Number of Output Ports

1 Unit

Water Tank Capacity

1.32 gal

Input Voltage

39 ~ 60V

Power

80W

Water Consumption

16.9 fl oz/h

Communication and Control Systems

XAG ACS4 Smart Handle

Model

M3ACS4A

Operating Frequency

SRRC: 2.400 GHz ~ 2.476 GHz

Equivalent Isotropic Radiated Power (EIRP)

2.4 GHz SRRC: ≤20 dBm

Signal Range (No Interference, No Obstruction)

1312.3 ft

Operating Environment Temperature

14 ~ 104 °F

Charging Environment Temperature

41 ~ 104 °F

Compatible Devices

XAG P150 2024 Agricultural Drone, XAG P60 2024 Agricultural Drone

XAG SRC4 Remote Controller with Screen

Model

M3SRC4A

Operating Frequency

SRRC: 2.400 GHz ~ 2.476 GHz; 5.725 GHz ~ 5.829 GHz

Equivalent Isotropic Radiated Power (EIRP)

2.4 GHz SRRC: ≤20 dBm; 5.8 GHz SRRC: ≤30 dBm

Signal Range (No Interference, No Obstruction)

6561.7 ft

Operating Environment Temperature

14 ~ 104 °F

Charging Environment Temperature

41 ~ 104 °F

Compatible Devices

XAG P150 2024 Agricultural Drone, XAG P60 2024 Agricultural Drone

XAG DL1 Digital Link

Model

XAG DL1 Digital Link

Operating Frequency

SRRC: 2.400 GHz ~ 2.476 GHz; 5.725 GHz ~ 5.829 GHz

Equivalent Isotropic Radiated Power (EIRP)

2.400 GHz:

←33 dBm(FCC)

←20 dBm(SRRC/CE/MIC)

5.800 GHz：

←33 dBm(FCC)

←30 dBm(SRRC)

←14 dBm(CE)

Signal Range (No Interference, No Obstruction)

SRRC: 1.24 miles

FCC: 1.24 miles

Battery Capacity

14.7 Ah

Charging Voltage

5V 3A / 15V 2A

Protection Rating

IP 65

XAG XRTK6 Handheld Mapper

Model

M3RTK6A

Positioning Accuracy

Single-Point Positioning (RMS)

Horizontal: 4.9 ft

Elevation: 8.2 ft

RTK (RMS)

Horizontal: ← 2 in + 1 ppm

Elevation: ← 3 in + 1 ppm

Frequency Bands

BDS: B1I, B2I, B3I

GPS: L1C/A, L2P(Y)/L2C, L5

GLONASS: L1, L2

Galileo: E1, E5a, E5b

Battery Capacity

4.8 Ah

Comparison

XAG P150 (Spray All Day Kit)

More Info

18.5 Gal (70L)

Capacity

tbd

Coverage

8 GPM (30LPM)

Max Flow Rate

	XAG P150 (Spray All Day Kit)

Frequently Asked Questions

Do you offer technical support for XAG drone repairs?

Of course! HSE provides unlimited technical support and troubleshooting for all of our customers. Whether you need help figuring out the best way to spray a challenging field, diagnosing a weird error, or finding the right replacement part, our experts are here to assist. Although XAG drones are designed to be easily serviceable by the end-user, HSE also offers repair services if you don’t want to mess with it.

What are the differences between XAG Chinese models and INTL (U.S.) models and parts?

XAG manufactures two different product lines: one for the Chinese market and one for the rest of the world. As you might expect, the American buyer demands the best, and the Chinese market is more price-sensitive, so XAG makes changes to quality and components to serve both markets. To combat grey market sales and possible compatibility issues, electronic components (i.e., drones, batteries, remote controllers, chargers, RTK, flight controllers, etc.,) are geo-locked and will only work in their authorized region. Got questions about any of this? Get in touch with us.

What about parts from other countries?

XAG calls these “grey market” parts and buying them might look attractive with a lower price, but buying parts from non U.S. licensed XAG companies (like HSE), will void your warranty. Why and what’s the difference? See below

How easy are XAG drones to repair?

That’s one of the things we really love about XAG - they are built to be serviced by the end-user! Plus, our XAG drone gurus can walk you through the process, and our parts diagrams help you find everything down to the tiniest little screw.

What replacement parts are available for XAG drones?

We offer a full range of replacement parts for XAG drones, including propellers, motors, nozzles, batteries, flight controllers, and more. Although most parts identify the compatible models, if you're unsure about compatibility, our team is just a call away.
